Euler CTX
Compact Fanless Case for Industrial & Long-Life Thin Mini-ITX Motherboards
Compact fanless Thin Mini-ITX case for Intel Core™ and Core™ Ultra processors (8th-15th Gen) up to 35W TDP. Features two USB 3.2 ports and two USB 2.0 ports. Suitable for VESA monitor mounting, saving valuable desk space. Ideal for industrial automation, point-of-sale (POS), digital signage or other long-life applications.
Patented spring mounting system ensures support across a diverse range of Thin Mini-ITX form factor boards across pro-business, industrial and long-life applications.
Ideal for industrial automation, point-of-sale (POS), kiosk, digital signage, education, surveillance or transportation systems.
Supports Intel® Core™ (8th-14th Gen) & Core™ Ultra (15th Gen) processors up to 35W TDP.
Compatible with Intel® LGA1851 / LGA1700 / LGA1200 / LGA115X sockets.
Fanless aluminium design efficiently dissipates heat from the CPU through the chassis fins, while eliminating noise and mechanical failure points, ensuring stable, long-term performance.
Measuring just 215mm in depth, 58.3mm in height, and 239.5mm in width, the Euler CTX boasts a small footprint with a compact 3L size that seamlessly fits into any environment. Its compact size makes it an ideal choice for space-constrained areas, ensuring that you get powerful performance without the bulk.
Premium aluminium case for hi-heat dissipation and durability. Brushed finish for a sleek and stylish look.
The Euler CTX case boasts a design that is over 22% more compact than the Euler TX3 case, optimising space without compromising functionality. Note, the Euler TX3 is able to support a 2.5'' drive.
Supports VESA mounting, enabling secure installation and a clutter-free environment.
Easily connect your fanless mini-PC to Wi-Fi with optional external antenna (A-ATN01-BK) and corresponding pigtail (A-ATC01-150GR)
Optional bespoke engraving and colouring solutions to highlight and differentiate your fanless system solution. Requires a minimum order quantity - please talk to our Team about the different options available.
Contact Us >
| Material | Aluminium with anodised black |
|---|---|
| Motherboard Types | Thin Mini ITX |
| Socket Support | Intel® LGA1851, LGA1700, LGA1200, LGA115X |
| Maximum TDP Support | 35W |
| Dimensions | 239.5 x 215 x 58.3 mm (W x D x H) |
| Volume | 3.0L |
| Drive Bays | Only suitable with M.2 SSDs |
| Front I/O Interfaces | USB 3.2 x2, USB 2.0 x2, Power button, Power & hard drive LEDs |
| Rear I/O Interfaces | Antenna fitting holes x2, kensington lock hole |
| Antenna Fitting Holes | 2 |
| Security | Kensington lock |
| VESA Mounting | Supported |
| Optional External Power Adapter | AC 120W or 150W |
| Product Code | A-ITX60-S1B |
